HAND LOWERING CONTROL- 3
POSITIONS
Lifting - neutral - lowering. Foot pedal is an added feature.
Neutral allows free handle movement when the truck is in motion. The handle
returns automatically to the vertical position.
The hydraulic system is the result of years of research and
development, including a load limiter that prevents premature wear resulting
from overloading. A special design of lowering valve permits gentle lowering of
heavy loads. No moisture can get into the unit and it is leak
proof.
| WARRANTY |
| Atlas warrants this equipment, when used under normal operating
conditions excluding acid and alkali environments, to be of proper materials
and
first class workmanship. We agree to exchange, excluding labor, any defective
moving parts (bearings and wheels, and hydraulic parts, not including the
chassis) returned to us by prepaid freight within 12 months from date of
shipment. |
| QUALITY FEATURES |
- Safety designed loop handle,includes neutral position,and fingertip release
- Spring-a-matic handle self returns to vertical posiiton
- 215° pivot action maneuvers in compact area
- One piece formed steel C-channel tapered, reinforced forks
- Leak-proof pump assures maintenance-free
- Hard chrome-plated ram and piston
- Urethane seals and wipers
- Large steer wheel with "Ball-Thrust" steering
- Sealed ball bearing throughout
- All pivot points can be lubricated easily
- Tapered fork ends and nylon rollers permit easy entry and exit of pallets
- Polyurethane steel wheels and load rollers
- Only 1 snap ring and 4 pins to remove the hydraulic unit
- Powder coated quality safety color after anti-rust treatment
|
SPECIFICATIONS
| Load capacity
|
| 5,500 lbs.
| |
| Lowered height of forks
|
| 2.9"
| |
| Raised height
|
| 7.2"
| |
| Overall width across forks (a)
|
| 27"
| |
| Fork width
|
| 6.3"
| |
| Space between forks (b)
|
| 14.4"
| |
| Standard fork lengths (l)
|
| 48"
| |
| Load rollers - polyurethane
|
| 2.9" x 3.7"
| |
| Front wheels (steer) - polyurethane
|
| 7" x 2"
| |
| Body length (including pump)
|
| 14"
| |
| Load roller axle to fork-tip end of truck:
| |
| Roller down
|
| 7.83"
| |
| Roller up
|
| 9.84"
| |
| Approximate weight
|
| 180 lbs
| |
